Why Does Pottery Break in Kiln: A ScienceBased Explanation

Why Does Pottery Break in Kiln

Pottery breaks in the kiln primarily due to residual moisture left in the clay.

Even when pottery appears dry, there can still be moisture present, which turns into steam when the kiln reaches 212F.

The rapid expansion caused by the steam leads to the shattering of the pottery.

This is especially common during the bisque fire, as the greenware still contains water content.

Water in the clay, both mechanically and chemically bonded, is the main cause of pottery explosions.

Other factors that contribute include trapped air bubbles or pockets, thick walls in pottery, carbon burn-off, and quartz inversion.

Pre-heating the kiln and allowing moisture to escape through the kiln door or peephole plugs can help prevent pottery from breaking in the kiln.

Did You Know?

1. Ancient Egyptians discovered that adding powdered quartz to their clay mixture helped prevent pottery from breaking in the kiln, making their pottery more durable.

2. The phenomenon of pottery breaking in the kiln is often caused by uneven heat distribution during the firing process. This can lead to stress building up within the clay, eventually causing it to crack or shatter.

3. A technique called “saggar firing” is sometimes used to protect delicate pottery from breaking in the kiln. In this process, the pottery is placed inside a protective container called a saggar, which acts as a shield against extreme temperature fluctuations.

4. The thickness of the pottery can play a significant role in its ability to withstand the kiln’s heat. Thin-walled pottery is more prone to breaking due to faster heat absorption and expansion, while thicker pottery has a higher chance of surviving the firing process intact.

5. The cooling process after firing, also known as “annealing,” is crucial in preventing pottery from breaking in the kiln. It involves slowly bringing down the temperature of the pottery to allow it to contract and stabilize, reducing the risk of cracks or fractures.

Residual Moisture: A Recipe For Kiln Explosions

Pottery, a craft that dates back thousands of years, seems to defy the laws of nature as it transforms from a malleable clay form into a hardened, beautiful object. However, this alchemical process doesn’t always go according to plan. One of the greatest challenges faced by potters is the risk of their creations breaking or even exploding in the kiln.

This phenomenon can be attributed to residual moisture that remains in the clay, even when it appears dry.

The dangers of residual moisture become most apparent when the kiln reaches 212°F (100°C), the boiling point of water. At this temperature, any remaining moisture in the clay turns into steam, rapidly expanding and creating immense pressure within the pottery. Inevitably, this pressure causes the fragile structure to shatter, and the heartbreaking result is a broken piece instead of a beautifully fired work of art.

  • Residual moisture in clay poses a risk for potters
  • Kiln reaching 212°F (100°C) causes the moisture to turn into steam
  • Steam expansion creates immense pressure leading to breakage and explosions

The Bisque Fire: A Time Bomb For Pottery

One critical stage in pottery firing that poses a high risk of kiln explosions is the bisque fire. During this process, the greenware, which is unfired clay, is heated to a relatively low temperature to remove any remaining water content. Despite the appearance of dryness, the greenware still contains water at both a mechanical and chemical level.

Mechanical water refers to the water physically trapped within the clay’s structure, tightly bound to its particles. On the other hand, chemical water is water that has chemically bonded to the molecules of the clay. It is the presence of these two types of water content that significantly contributes to the explosive potential of pottery in the kiln.

Water Content: The Culprit Behind Pottery Explosions

It is crucial to understand that the presence of water in the clay is the primary cause of pottery explosions. Even the slightest amount of moisture left behind can have catastrophic effects, showing just how delicate the balance is in the firing process. To mitigate this risk, potters take special care to remove free water from their pieces during the preheating stage.

Prior to reaching higher temperatures, the kiln undergoes a water smoking stage. This step is vital as it allows the free water within the clay to evaporate before it has a chance to expand and cause damage. By carefully controlling the rate of temperature increase, potters can ensure that any remaining water content is safely evaporated, reducing the risk of explosions.

Trapped Air: A Hidden Danger In Pottery Firing

While moisture is undoubtedly the primary cause of pottery explosions, the presence of trapped air can also contribute significantly to this risk. Air bubbles or pockets within the pottery provide a space for moisture to evaporate and expand, further exacerbating the pressure buildup during firing. This phenomenon is particularly prevalent in thick-walled pottery, where the risk of explosions is heightened.

Given these risks, it is essential for potters to take preventive measures to minimize the potential for air entrapment. This includes methods such as clay kneading and proper wedging techniques to ensure a more uniform structure throughout the pottery.

  • Clay kneading
  • Proper wedging techniques

Pre-Heating: A Key Step In Preventing Kiln Explosions

To prevent kiln explosions, potters must employ specific techniques during the firing process. One of the crucial steps is preheating, also known as candling. Preheating involves gradually raising the temperature in the kiln to remove any mechanical water before the main firing begins.

Preheating not only helps remove residual moisture, but it also aids in driving out any remaining air trapped within the clay. By following this meticulous process, potters can significantly reduce the risk of kiln explosions and increase the likelihood of successful firings.

Moreover, leaving the kiln door slightly open or removing peephole plugs during the initial stages of firing allows for any excess moisture to escape more effectively. This controlled release of moisture ensures that the pressure within the kiln remains at safe levels, further reducing the likelihood of explosions.

In conclusion, the risks of pottery breaking or exploding in the kiln can be attributed to residual moisture left in the clay, particularly during the bisque fire. The water content, both mechanically and chemically bonded, is the primary cause of these destructive events. Additionally, the presence of trapped air and thick walls in pottery can exacerbate the risk.

To minimize the potential for kiln explosions and increase the chances of achieving successful firings, potters should:

  • Preheat the kiln gradually to remove mechanical water and trapped air.
  • Leave the kiln door slightly open or remove peephole plugs during the initial stages to allow for controlled release of excess moisture.

Check this out:


Frequently Asked Questions

Why did my pottery crack in the kiln?

The cracking of pottery in the kiln can be attributed to the rapid cooling process. If the kiln cools too quickly, sharp-edged cracks may appear on the pottery surface. To prevent this, it is recommended to fire down the kiln gradually. By using a controlled cooling program in computer-controlled kilns, you can eliminate a significant number of cracks caused by the rapid cooling process. Consulting your kiln’s manual will likely provide you with the instructions on how to engage the controlled cooling program.

Why might a piece break in a kiln firing?

In addition to the risk of moisture causing greenware to explode, there are other factors that can contribute to a piece breaking in a kiln firing. One such factor is uneven drying of the clay. If the clay is dried too quickly or unevenly before firing, it can create internal stresses within the piece. These internal stresses can lead to cracking or breaking when exposed to high temperatures in the kiln.

Furthermore, the composition and preparation of the clay itself can also affect its ability to withstand the firing process. If the clay body is not properly formulated or if it contains impurities, it may not have the necessary strength or stability to withstand the thermal expansion and contraction that occurs during the firing process. This can result in the piece breaking or developing structural weaknesses.

Therefore, while moisture and the resulting steam pressure pose a significant risk, it is important to consider other factors such as drying conditions, clay composition, and preparation techniques to ensure the successful firing of ceramic pieces in a kiln.

How do you fix cracked pottery before firing?

To fix cracked pottery before firing, you can start by preparing a mixture of paper clay using the same clay body as the pottery. Incorporate a few drops of clear glaze and finely grounded bisque from the same clay. Begin by cleaning the cracked area from any dust and applying clear glaze. As the glaze dries, there might be a chance that some cracks reappear, but simply continue filling them with more paper clay until the surface is smooth and even. This process ensures that the cracks are securely sealed and ready for firing.

Why do some types of pottery break in the kiln while others remain intact?

The way pottery interacts with the kiln and survives the firing process depends on a variety of factors. One key factor is the type of clay used. Different clays have different mineral compositions and molecular structures, which affects their ability to withstand high temperatures. Some clays are more heat-resistant and have a higher tolerance for thermal expansion and contraction, making them less likely to break in the kiln. On the other hand, certain clays may contain impurities or have a high moisture content, causing them to crack or explode when exposed to intense heat.

Furthermore, the design and thickness of the pottery piece also play a role in its ability to endure the firing process. Thick pottery may have uneven heat distribution, which can lead to stress and breakage. Conversely, thinner and more uniform pieces are less prone to thermal shock and are more likely to remain intact. Additionally, the shape and composition of the pottery object can influence how it responds to the kiln’s heat, with intricate or fragile designs being more susceptible to breakage. Ultimately, the combination of clay type, moisture content, thickness, design, and firing technique determines why some types of pottery break while others survive the kiln unharmed.
